Water source heat pump unit

The HR/HRL series water source heat pump unit is an existing company in Dongguan Huarui Refrigeration Equipment Co., Ltd.Refrigeration equipmentOn the basis of, the series of products developed and produced for the utilization of water resources are manufactured with famous-brand compressors and electronic control components, equipped with high-efficiency and high-quality shell and tube condensers and evaporators; compact structure, sufficient cooling capacity, high efficiency, Easy to clean and maintain. It has two functions of cooling and heating, which is different from the single cold chiller.

The HR series scroll water source heat pump unit has more than a dozen specifications, while the HRL series screw water source heat pump unit has dozens of specifications. The HR series refrigeration range is 7654kcal/h~117906kcal/h, and the heating range is 9632 kcal/h~145770kcal/ h, HRL series refrigeration range is 81356kcal/h~2746840kcal/h, heating range is 88580kcal/h~2958400kcal/h. Different from other industrial refrigeration equipment, heat pump units can be applied to industrial and commercial places that require cooling and heating.

Unit characteristics:

The unit has 7 safety protection measures to ensure the normal operation of the unit.

The unit is equipped with single and double loop designs to meet the different choices of customers. When a single compressor of a dual-circuit configuration unit fails, the other compressor can still operate normally without affecting customer use.

All units are 100% tested by the safety inspection system before leaving the factory to ensure that the unit's performance meets corporate standards.

The unit is controlled by a microcomputer and can be operated through a centralized management system. The unit can be equipped with a remote management program to feed back system operation information and realize remote service.

The unit has been filled with refrigerant and lubricating oil before leaving the factory. Customers only need to connect the inlet and outlet pipes and the power supply to operate.

The control interface directly displays the fault content, which is convenient for timely understanding and troubleshooting.

The unit can be flexibly designed according to the conditions of the machine room, and it can be delivered in spare parts and assembled on site.

The chiller produces units with different power supply formats according to the power supply of different countries and regions.

The unit can provide R22, R407C, R134a and other refrigerants according to customer needs.
